Unior Offset Open Ring Wrench 8×10
Material: premium chrome vanadium steelDrop forged, entirely hardened, and temperedSurface finish: chrome plated according to ISO 1456:2009Profile up to dimension 12x14 is 6 point, from 17x19 to 30x32 is 12 pointUsage:In industry and repair shops specializ
Category: Tools
- Material: premium chrome vanadium steel
- Drop forged, entirely hardened, and tempered
- Surface finish: chrome plated according to ISO 1456:2009
- Profile up to dimension 12×14 is 6 point, from 17×19 to 30×32 is 12 point
Usage:
- In industry and repair shops specializing in hydraulic and pneumatic installations
- This wrench helps to work on joints where the use of a standard ring wrench is impossible due to the nature of the job (ex. unions on steel cables, hydraulic and water pipes and valves, etc).
| Product Code | Wrench Size | Length (L) | Thickness (A1) | Thickness (A2) | Width (B1) | Width (B2) | Additional Length (C1) | Additional Length (C2) | Weight |
|---|---|---|---|---|---|---|---|---|---|
| 612701 | 8 x 10 | 145 | 7 | 8.5 | 18 | 20 | 6 | 7 | 48 |
| 612702 | 10 x 11 | 152 | 8.5 | 9 | 20 | 22 | 7 | 8.5 | 64 |
| 612703 | 11 x 13 | 165 | 9 | 11 | 22 | 26 | 8.5 | 10 | 88 |
| 612704 | 12 x 14 | 178 | 10 | 12 | 24 | 28 | 9 | 11 | 125 |
| 615147 | 16 x 18 | 196 | 12 | 12.5 | 30.5 | 33.5 | 13 | 14 | 203 |
| 612705 | 17 x 19 | 210 | 13 | 14 | 32 | 35 | 14 | 15 | 204 |
| 612706 | 19 x 22 | 233 | 14 | 16 | 35 | 41 | 15 | 17 | 242 |
| 612707 | 22 x 24 | 265 | 16 | 17 | 41 | 45 | 17 | 18 | 297 |
| 612708 | 24 x 27 | 265 | 17 | 17 | 45 | 48 | 18 | 20 | 367 |
| 612709 | 30 x 32 | 285 | 21 | 23 | 50 | 52 | 22 | 24 | 552 |
* Images of products are symbolic. All dimensions are in mm, and weight in grams. All listed dimensions may vary in tolerance.
