SCULTURA COLLECTION

LIGHTWEIGHT RACE PEDIGREE

SCULTURA LITE FRAME

Lightweight 6066 triple butted aluminium frame with tapered head tube for precise steering and Press-Fit 86 bottom bracket for effective power transfer. Featuring internal cable routing and aero profiled tubing.

PRECISE STEERING

All models feature a full carbon fork with a tapered steerer to give precise, confidence inspiring handling. Aluminium and CF2 carbon models feature a regular 1 1/8″ to 1 1/2″ taper. The high end CF4 frame has a slimmed down front profile and uses a 1 1/8″ to 1 1/4″ taper.

AERO PROFILED TUBING

Our wind tunnel learnings from the REACTO design project have been used to create a smaller aerodynamically optimised NACA Fastback tube profile. The more extreme truncation of the teardrop shaped tubes enables perfect airflow at the lowest possible weight.

CLASS-LEADING FRAME WEIGHTS

Our top end CF4 frame brings in 850 g (size M/L) in the caliper brake version whilst the CF4 Disc frameset tips the scales at 1000 g (size M/L). Incredible readings while offering a lifetime warranty on all our frames, even when raced.

25 MM TYRES

The SCULTURA DISC and rim version can be fitted with 25 mm wide tyres, providing maximum traction and transferring the improved braking power to the road. The 25 mm tyres also offer improved comfort.

SPECIFICATIONS:

FRAMESCULTURA LITEFRAME SIZEXXS, XS, S, S/M, M/L, L, XLCOLORBLACK (TEAM REPLICA)FORKSCULTURA CFBRAKE FRONTMERIDA ROAD CompBRAKE REARMERIDA ROAD CompBRAKE LEVERShimano TiagraHEADSETMERIDA M2339 NeckHANDLEBARMERIDA Expert SLHANDLEBAR STEMMERIDA Expert CCGRIPMERIDA Road ExpertDERAILLEUR (F)Shimano Tiagra DFDERAILLEUR (R)Shimano TiagraSHIFTER FRONTShimano TiagraSHIFTER REARShimano TiagraSEAT POSTMERIDA Expert CCSEAT CLAMPMERIDA ExpertSADDLEMERIDA Comp SLCHAINKMC X10-1CHAINWHEELShimano TiagraFREEWHEELShimano CS-HG500BOTTOM BRAKETShimano Pressfit BBRS500-PBRIMMERIDA Comp SLTIRE FRONTMaxxis DolomitesTIRE REARMaxxis DolomitesHUB FRONTVP M700FHUB REARVP M700RAXLE FRONTQRAXLE REARQRSPOKESBlack stainlessWEIGHT9.07 kgGEOMETRIES:
