Cervelo Road Bikes | S2 Shimano 105 (2018)
Cervelo's S2 combines aero tubing and stiff, tight geometry for a super-fast and comfortable all-rounder. From the rear wheel cutout to the wide seat and down tubes, every aspect of the frame minimizes wind drageven the position of your water bottles reduc
Cervelo’s S2 combines aero tubing and stiff, tight geometry for a super-fast and comfortable all-rounder. From the rear wheel cutout to the wide seat and down tubes, every aspect of the frame minimizes wind drageven the position of your water bottles reduces turbulence. Race-ready geometry and the fork’s tapered steerer bolster your cornering prowess, while thin seat stays reduce road chatter so you stay fresh for the county-line sprint. Smooth, efficient shifting is at your disposal thanks to 11-speed Shimano 105 components and the Shimano RS510 crankset. You also get Shimano wheels, brakes and Cervelo’s seamlessly integrated aero seatpost. Slice through the wind and catapult out of the corners with Cervelo’s S2.
Features
- BBright: This asymmetrical 79mm bottom bracket standard yields stiffer and lighter frames and crank systems
- Carbon dropouts: Tough, compression-moulded dropouts save weight with no sacrifice in strength compared to traditional metal dropouts
- Future-proof cable management: Ensures your frame is compatible with all current and future derailleur and brake systems
- Partial seat tube cutout: A close-fitting curve in the seat tube’s trailing edge improves aerodynamics by partially shielding the leading edge and top of the rear wheel
- Reduced-friction BB guide: Significantly reduces cable friction in the bottom bracket, which means smoother shifting, easier setup and longer service intervals.
Specifications
- Frame: Cervelo S2 carbon
- Fork: Cervelo All-Carbon, Tapered S2 Fork
- Headset: FSA IS2 1-1/8 x 1-3/8″
- Rims/Wheels: Shimano RS010
- Tires: Continental Grand Sport Race, 700x23c
- Crankset: Shimano RS510 50/34
- Bottom Bracket: BB Bottomfit BBO-72, PF30 Threaded
- Chain: Shimano HG600, 11 spd
- Front Derailleur: Shimano 105 5800, 11 spd
- Rear Derailleur: Shimano 105 5800, 11 spd
- Cassette: Shimano 105 5800, 11-speed: 11-25
- Shifters: Shimano 105 5800, 11 spd
- Handlebars: Cervelo Performance Alloy Compact
- Stem: Cervelo Performance Alloy
- Brakes: Shimano 105 5800
- Saddle: Cervelo Comfort Race
- Seat Post: Cervelo Carbon, Aero.
Geometry & Sizing
| Size | 48 | 51 | 54 | 56 | 58 | 61 |
|---|---|---|---|---|---|---|
| Stack | 505 | 530 | 555 | 580 | 605 | 630 |
| Reach | 360 | 369 | 378 | 387 | 396 | 405 |
| Effective Seat Tube Angle | 73 | 73 | 73.0 | 73 | 73 | 73 |
| Top Tube | 516 | 531 | 548 | 564 | 581 | 597 |
| Wheel Size | 700C | 700C | 700C | 700C | 700C | 700C |
| Head Tube Angle | 70.5 | 72.2 | 73.1 | 73.5 | 73.5 | 73.5 |
| Fork Offset | 53 | 53 | 43 | 43 | 43 | 43 |
| Head Tube Length | 108 | 128 | 148 | 173 | 199 | 225 |
| BB Drop | 68 | 68 | 68 | 68 | 68 | 68 |
| Front Center | 575 | 575 | 575 | 587 | 604 | 620 |
| Rear Center | 405 | 405 | 405 | 405 | 405 | 405 |
| Stand Over Height | 693 | 723 | 753 | 784 | 815 | 846 |
